HMS build Ref: 303/2011

Overview: 3 Car transporter, Living accommodation to accommodate four people, Awning and Generator.

2011 HMS race conversion.

External height 4100m at travelling height 1200mm on 5^th wheel

Chassis No:. Id No:

Bench to ceiling height 1510mm

Top deck height: 1430mm (approx) Top deck length: 9485mm

Paintwork:  Blue & white.

Mot: 12 months

Tail lift: 2000kg 2tier Dhollandia double deck lift fitted with:

HMS race spec platform and hydraulic folding mechanism, strengthened columns with new HMS runners & nylon, new bearings in all pulleys, Max lifting car capacity 1500kg@ 1000mm. Side brush seal and rubber top seal. Automatic hand rails

Hydraulic power pack: new HMS with 5 buttoned pendant removable hand control/

Lower deck/workshop

Internal lower deck height: 2010mm Lower deck max car length: 5,400mm

Internal lower deck bench height: 510mm

Carrying capacity 1 car on the bench’s, with room for tyre trollies at the rear, fixed overhead lockers, full height front cupboard (currently fitted with a washing machine).

Living Area:

Master Bedroom

Bed: Size 1500mm (5ft)1960mm approx 400mm from floor with storage below.

Wardrobes: 2x 600mm wardrobes

Overhead: Full length overhead lockers on 1 wall.

Walls: Finished in cream sued.

Ceiling: Finished in gloss white.

Doors: Sliding door into landing area.

Floor: Short pile carpet.

Window: 1 x slanted window

Heating: Electric plinth heater. Additional diesel heating fitted in 2013.

Skylight: 700mm x 700mm with blind

Other: Clean water tank, water pump and 240volt mains 45litre water heater fitted below bed.

Wet Room/Shower Room

Shower tray 760mm x 900mm.

China corner vanity unit & basin.

Ceiling finished in high gloss white.

Walls finished in high gloss white.

Sliding door into bedroom area.

1x mirror & towel rail

Toilet / Wash room

1x China Macerator toilet.

1x vanity unit with fitted sink.

1x mirror & towel rail

Floor: Solid floor finish

Window: 1x window for ventilation.

Ceiling: Finished in gloss white.

Landing area:

The landing area will incorporate steps to the top deck and access to the shower room, wc room and bedroom through sliding doors.

All landing area walls melamine board of colour to suit Ceiling finished in high gloss white.

12 volt & 240volt lighting

Kitchen Area:

Steps leading from bedroom to kitchen/ living area with partition between units and stair way. Steps finished

in laminate,

All wall finished in melamine to suit.

Ceiling finished in polished chrome slotted panels, with 12volt and 240 volt down lighting or sued.

Smev sink and drainer with fold down lid.

1x Microwave oven wall mounted above the fridge

1x 500m width fridge operating on 240v/gas&12V. or taller 240 volt fridge.

Floor finish

Windows with blind integrated into wall above sink.

Over head lockers on external wall.

Lounge:

Seating finished in Brown leather

Drop down table to form additional double bed5. 2x opposite windows with recessed blinds.

22” LCD TV on wall mounted bracket.

Full length overhead units on both side walls, height approx 380mm

Generator:

Honda EU65 Generator. 6.5kw inverter based petrol silent generator.

Awning:

7m x 13.5m Awning Co, white sail cloth roof and white pvc side.

Notes:

The above transporter can be sold as is or modified to suit to any specification.

Additional fold down beds can be fitted in the top deck or workshop area if required.

The transporter can be sold with or without the tractor unit, the tractor unit is not included in the price.

Price Excluding tractor unit: £110,000+vat

Possible Rental option available to UK based team
