399-aext-good
399-aGibson-sticker
399-afront
399a-office-in
399a-office-out
399a-wshop-rear-bench-down
399a-wshop-out
399-adome-internals
399-ageni
This transporter was converted for 2015 and has been used in the WEC & ELMS championship’s it has a carrying capacity of 3 touring/GT cars on the top deck and 1 formula / radical size car in the workshop.
Overview: New build in 2015 on a used 2008 chassis,
External height: 4050mm at travelling height 1200mm on 5th wheel
Chassis No: SEPBV30CA8L05…… Id No: C2714…
Trailer: 2008 Don Bur chassis with 2014 HMS conversion including new side panels.
Internal lower deck height: 1920mm
Internal lower deck bench height: 930mm
Bench to ceiling height 1020mm
Top deck height: 1440mm (approx)
Paintwork: Mercedes Artic White in ICI Turbo 2k.
Mot: 12 months
Mechanics: New LED lighting, 12 months Mot all brakes, air bags & suspension components original, brakes at least 50% condition
Awning: No
Generator: Cummins 8.8kw diesel (mounted in the front locker)
Compressor: 2hp Piston (mounted in the dome)
Detailed Specs
Sides: New 32mm GRP finished internally and externally in 2mm high gloss white vetrosina GRP.
Mouldings: New flush fit mouldings, new aluminium side skirts with hinged wheel arch’s.
Dome: Pressed aluminium chamfered front dome, 2 x doors into storage area,
Doors: 1x HMS side doors with 1x internal step into workshop.
Lockers: 2x locker doors opening on gas struts on 1 side of the neck.
Length approx 1200mm, height approx 900mm, width: 2400mm
Tail lift: 2008 1,500kg @1,000mm 2 tier Dhollandia double deck lift as originally fitted to the trailer when built new in 2008.
HMS race specification platform and hydraulic folding mechanism, and automatic opening hand rails. Max lifting car capacity 1500kg. Side brush seal and rubber top seal.
Lift using new HMS power pack and controls and
Under neck: Pressed aluminium panel under neck to cover landing legs.
Air/Power: 1x air & power outlet and the rear for garage use.1x air & power outlet under the neck for awning use.
Roof: New 32mm high gloss white on both sides insulated roof with square external
mouldings.
Workshop/Car Area
Dimensions: Carrying capacity 1x Car max height 1010mm car length 680mm
Walls and ceiling: Finished in high gloss white, 3x double power sockets per side.
Lighting: Full length corner lighting on both sides
Floor: Finish in 3mm black circular stud matting.
Access hatch: Size approx 700mm x 800mm opening on a single gas Strut between lower deck and top deck.
Bench tops: Finished in 18mm phynolic non slip ply, covered in 3mm black non slip matting with stainless steel edges.
Top Deck
Walls & Ceiling: Gloss white
Lighting: Full length corner lighting on one side,
Tracking: Full length multi point tracking on one side wall.
Floor: 18mm mesh. With continuous multi load tracking (not recessed)
Height on top deck: 1450mm, length 13300mm.
Office Area
Walls: Grey Pamplona suede.
Floor: Black flec carpet.
Ceiling: Large silver slotted roof panel with recessed lighting.
Windows: 1x bonded slanted window per side
Seating: Bench seating finished in Black leather with storage below.
Seat bases: Finished in foam backed leatherette.
Fridge: 1x 500mm
Wardrobe: 1x 500mm wardrobe on opposite wall,
Overhead Units: Full length on both side walls
Access: Sliding door for access between lower car area/workshop and office.
Television: 42” LCD TV mounted centrally on the front wall.
Air-Con: Centrally mounted on the front wall (the external A/c machine will be mounted in the front dome)
Neck Storage: 2 doors length approx 1200mm each, height approx 900mm opening on gas struts into neck storage area. Door finished in high gloss white. The floor and ceiling are original, walls lined in high gloss white, 3x adjustable height shelves.
1 x 5ft fluorescent tube fitted.
